FL-F2216CTA160-WF0-5M-24-K008

The user can cut the light strip at any position, providing higher flexibility and adaptability for the light strip installation.The metal sinking technology can effectively prevent the oxidation of the pad, thus improving the reliability and stability of the welding.The immersion gold plating process boasts excellent conductivity and outstanding corrosion resistance.

  • 320 LEDs per meter design, low heat, uniform light emission.

  • Available in 2700K、 6000K

  • 90 color rendering index.

  • Lumen output ranging from 1075Lm to 1123Lm per meter.

  • IP rate: IP20、IP65、IP66、IP67、IP68

  • 5 year warranty.

  • Led with one BIN system, good color consistent.

  • Adopting alloy wire scheme, ultra-high brightness, stable and reliable.

  • CE/UKCA/ROHS certification

Description

Performance

STEP LENGTH

3.13MM/LEDs

NUMBER LED/M

320

VOLTAGE

24V DC

RA

90

BEAM ANGLE

120°

POWER

9.6W/M(CH)

FPC WIDTH

8MM

IP RATE

IP20/IP65/IP66/IP67/IP68

MAX. LENGTH PER CIRCUIT

5M

COLOR

2700K/6000K
