FL-F2835X60-WF0-10M-C-24-K010

The user can cut the light strip at any position, providing higher flexibility and adaptability for the light strip installation.The metal sinking technology can effectively prevent the oxidation of the pad, thus improving the reliability and stability of the welding.The immersion gold plating process boasts excellent conductivity and outstanding corrosion resistance.

  • 120 LEDs per meter design, low heat, uniform light emission.

  • Available in 2300K、2500K、2700K、3000K、3500K、4000K and 6000K

  • 80/90/95 color rendering index.

  • Lumen output ranging from 1160Lm to 1349Lm per meter.

  • IP rate: IP20、IP67

  • 5 year warranty.

  • Led with one BIN system, good color consistent.

  • Adopting alloy wire scheme, ultra-high brightness, stable and reliable.

  • CE/UKCA/ROHS certification

Description

Performance

STEP LENGTH

5MM/6 LEDs

NUMBER LED/M

120

VOLTAGE

24V DC

RA

80/90/95

BEAM ANGLE

120°

POWER

12.8W/M

FPC WIDTH

10MM

IP RATE

IP20/IP67

MAX. LENGTH PER CIRCUIT

10M

COLOR

2300K/2500K/2700K/3000K/

3500K/4000K/5000K/6000K
