FL-NFS1220-5000-24
Silicone extrusion process, integrated end cap design solution, protection grade IP67, suitable for swimming pool, building outline lighting, etc.
-
Available in 2100K、2700K、3000K、3500K、4000K、5000K、RGB、RGBW and CCT.
-
90 color rendering index.
-
Lumen output ranging from 296Lm to 361Lm per meter.
-
Cuttable anywhere with a maximum run of 30m.
-
Made from high-quality gas silicone, resistant to yellowing, UV rays, salt and alkali, high temperatures, and flame retardant.
-
IP rate: IP67
-
3 year warranty.
Description
Performance
STEP LENGTH
50/62.5/66.8MM
VOLTAGE
24V DC
CRI
90
POWER
50/62.5/66.8MM:12/12/14.4W
STANDARD LENGTH
5M/30M
MIN. BENDING
R>60MM
IP RATE
IP67
BEAM ANGLE
110°
COLOR
50MM:2100K/2700K/3000K/
3500K/4000K/5000K/CCT
62.5/66.8MM:RGB/RGBW
Specification Sheets
Catalogs/Brochure
Aluminum profile
L1000*W17.5*H20mm
Bendable profile
L1000*W13*H18.4mm
Mounting clips
L30*W14.1*H20mm
Screws
KA3*12
End cap/outlet from end
L22*W22*H14mm
End cap/outlet side
L20*W22*H12mm
End cap/outlet from bottom
L16*W22*H14mm
Wires
Silicone glue
10ml/pcs
M12 connector
M12 tee T line
Electrician angle scissors
Paddle scissors
Stainless steel wire hoop
Automatic Terminal Crimping
A Glue
B Glue
Plug adhesive
Injection machinefor end caps
L550*W610*H750mm
Mixing pipe consumables
Fastener mold - Reference
