FL-NFT1616B-5000-24
Top bending design, uniform light.Suitable for indoor and outdoor decorative lighting, architectural outline lighting, etc.
-
Silicone integrated extrusion technology.
-
Multiple CCT choices, and ensure batch color consistency.
-
Using high quality gas silica gel, yellowing resistance, UV resistance, salt and alkali resistance, high temperature resistance, flame retardant.
-
Available in 2100K、2700K、3000K、3500K、4000K and 5000K.
-
90 color rendering index.
-
Lumen output ranging from 477Lm to 593Lm per meter.
-
IP rate: IP68
-
3 year warranty.
Description
Performance
STEP LENGTH
50/62.5/66.8MM
VOLTAGE
24V DC
CRI
90
POWER
50/62.5/66.8MM:12/12/14.4W
STANDARD LENGTH
5M/30M
MIN. BENDING
R>60MM
IP RATE
IP68
BEAM ANGLE
110°
COLOR
50MM:2100K/2700K/3000K/
4000K/5000K/CCT
62.5/66.8MM:RGB/RGBW
Specification Sheets
Catalogs/Brochure
Aluminum profile
L1000*W17.5*H18.9mm
Aluminum profile
L1000*W17.85*H16.45mm
Mounting clips
L30*W17.5*H18.9mm
Screws
KA3*12
End cap/outlet from end
L28*W19*H19mm
End cap/outlet side
L19*W18*H29mm
End cap/outlet from bottom
L19*W18*H29mm
End cap/without hole
L19*W19*H15mm
Wires
Silicone glue
10ml/pcs
M12 connector
Electrician angle scissors
Paddle scissors
Stainless steel wire hoop
Automatic Terminal Crimping
A Glue
B Glue
Plug adhesive
Injection machinefor end caps
L550*W610*H750mm
Mixing pipe consumables
Fastener mold - Reference
